DC53 mold steel use:
1. Precision stamping die
Precision blanking dies for wire cutting and stamping dies for various purposes.
2. Tools for plastic deformation of difficult-to-machine materials
Dies for cold forging, deep drawing and wire rolling.
3. Others
High-speed blanking punches, steel plate punches.
DC53 mold steel properties:
1. High hardness after heat treatment
After high temperature tempering, it can reach 62-63HRC high hardness, high in strength and wear resistance
2. Strong toughness
The toughness of DC53 is more prominent in cold work die steel, and it is made of DC53
The tool rarely cracks and cracks, greatly improving the service life.
3. The residual stress after cutting is small
The residual stress is reduced by high temperature tempering, and the wire cutting process
Cracks and deformation are suppressed.
