CR8 cold work die steel

  Introduction of CR8 die steel:

CR8 can not only ensure high hardness and high wear resistance, but also avoid the disadvantage of poor toughness and easy brittle cracking of this steel; appropriately increasing the content of silicon and manganese can improve hardenability. The steel has high hardenability, high hardness and high wear resistance.

Chemical Composition of CR8 Die Steel

Chemical composition (%): Carbon C: 1.60～1.90 Silicon Si: 0.20～0.60 Manganese Mn: 0.20～0.60

            Sulfur S: ≤0.030 Phosphorus P: ≤0.030 Chromium Cr: 7.50～8.50

            Nickel Ni: Allowable residual content ≤ 0.25 Copper Cu: Allowable residual content ≤ 0.30

 CR8 die steel use

Used to make complex or precision stamping dies and drawing dies; suitable for cutting and processing

Cold working dies and screw rolling gears, deep drawing dies, stainless steel plates

Stamping dies, punches and cold forging dies. Mainly used in the manufacture of high-efficiency cutting tools.

Because of its high red hardness, good wear resistance and high strength, it is also used in

Manufacture molds with high performance requirements, high temperature bearings and high temperature spring steel, etc.

 CR8 Die Steel Properties

1. Vacuum degassing and refining treatment to make the steel pure.

2. Spheroidizing annealing softening treatment, good cutting performance.

3. The strengthening element vanadium and molybdenum are specially added, and the wear resistance is extremely excellent.

4. All kinds of scissors, inlaid blades, woodworking blades.

5. Deep drawing die, cold extrusion die.

6. Efficient blanking die, punching die and embossing die.

 CR8 die steel price

Please contact us by phone: 13713200026 for the current quotation, please scan the QR code below.

Landline phone: 0769-33549898

ASSAB Heat Treatment Co., Ltd. sells various imported and domestic steel products with complete specifications.

Wholesale and retail of original factory warranty can be provided for mold steel, high speed steel, stainless steel,

One-stop service for alloy steel, tungsten steel, milling, vacuum heat treatment, and drawing processing.
